20-110-60-PSI/KPA NOSHOK, Inc. 0 to 60 psi Range Acrylonitrile Butadiene Styrene (ABS) and Steel Case Dry Pressure Gauge

Item #: 461000100

Availability:

Accurate and reliable general purpose dry gauge with vacuum & compound ranges, and ABS or Steel case. Ideal for applications including hydraulics, pneumatics, medical, pumps, compressors, refrigeration controls and more.

Multiple connection options are available including panel mount. A wide variety of pressure ranges, scale options, connections sizes, and options including flanges, case options, cover rings, lens materials, pointers, and orifices are also available.

Product Name	100 Series Acrylonitrile Butadiene Styrene (ABS) and Steel Case Dry Pressure Gauges
Connection Type	National Pipe Thread (NPT)
Connection Size	1/4"
Connection Material	Brass
Case Material	Acrylonitrile Butadiene Styrene (ABS)
Case Type	Acrylonitrile Butadiene Styrene (ABS), Back Connection
Lens/Display Material	Acrylic
Dial/Display	White background with black primary scale & red secondary scale. UV resistant.
Gauge Size	2"
Measuring Element	Copper Alloy Bourdon Tube
Bezel Material	Built-in bezel, molded as an integral part of the case for ease of panel mounting.
Pointer	Molded Plastic
Movement	Brass & nylon, or all-brass with highly polished bearing surfaces
Scale Option	psi/kPa Dual Scale
Accuracy	2.5%
Pressure Range	0 to 60 psi
Ambient Temperature Range	-40 to 60°C -40 to 140°F
Media Temperature Range	-20 to 60°C -4 to 140°F
